Alfa Laval tricanter centrifuge, NX 438B-11G

Alfa Laval tricanter centrifuge, NX 438B-11G

Max. bowl speed, rpm: 3650

Max. density of solids, kg/dm3: 1,2

Max product temperature, deg. C: 110

Gear box: 3,5 kNm

Back drive system: Motor drive: 11,0 kW - 50 Hz, 400 V. 2940 rpm.

Main drive: 75 kW, 50 Hz, 1480 rpm

Operating G-force: 3.193, max bowl speed: 3650 rpm. Gearbox: 3,5 kNm, Back drive: VLT motor drive. Drum diameter: 480/263 mm, Beach angle: 10°, 95 mm pitch, conveyor flights are protected with hard metal surfacing to protect against abrasive wear, BD3 feed inlet, max sludge density: 1,2 kg/dm3, wear liner providing 360° overflow rim for solids discharge, saddles for erosion protections, max feed temperature: 110°C. Oil discharge radius: 135 mm level ring.

Capacity:

Fish press liquid, m3/hour: 15-30

Cooked fish mass, m3/hour: 10-20

Wet rendering press liquid, m3/hour: 10-20

Actual througputs depend on variables such as amount and type of solids, temperature, visosity and degree of clarification and/or solids dryness required.

This unit has recently been totally reconditioned by SPOMASZ-Wronki decanter factory work shop in 2020. The unit is now in our stock and ready to be put back in operation.

The tricanter unit will be delivered without electrical panel and without lifting tools.

We have in stock an original Alfa Laval control- and steering panels for automatic operation of a NX 438 decanter unit designed for a 55 kW main motor and for a 11 kW back drive motor. The main motor and the back drive motor, are connected via frequency converters to the Alfa Laval Differential Speed Control (DSC) system. We can optionally offer the tricanter unit with this electric panel and a 55 kW main motor.

Also, optionally, we can offer this tricanter unit with lifting tools and other special tools.

Dimensions and weight for the tricanter unit as to the pictures: L 4,8m x W: 1,2m x H: 2,2m - estimated weight: 5 tons.
